        WisenMeshWAN® Wheatstone Bridge Interface Node is compatible with all different brands of high-quality strain gauge in a Wheatstone Bridge arrangement at 4 wires or 6 wires formats. Examples of sensors:

    1.  Encardio, Load Cell: https://www.encardio.com/geotechnical-products/center-hole-load-cell

    2.  Sisgeo, Load Cell: https://sisgeo.com/products/load-cells/electric-anchor-load-cells/

    3.  Geosense, Load Cell: https://www.geosense.com/products/strain-gauge-anchor-load-cells-sglc-7000/

    4.  LCM Systems Ltd, LPB Custom Designed Stainless Steel Load Measuring Pin: https://www.lcmsystems.com/lpb-custom-design-load-pins

    5.  Geokon Load Cells (Electrical Resistance) | Model 3000: https://www.geokon.com/3000

    6.  Plus ALL the sensors of the same type and working principle.


Casing and Painting Materials:  Aluminium-Alloy Die Castings 12 (Epoxy Polyester Powder Coating)
IP Rating:  >= IP66
Operating Temperature:  -40 to 85°C
Fire Proof:  Approved

  • Product Calibration Certificate: Downloadable from WiSen® Visualisation Platform, under /Download & Upload/Calibration & Document & Software/Calibration.
    Note: Every unit from WiSen has been fully electrically tested, calibrated, radio verified and mesh examined while individual calibration certificate is issued before shipped to our global customers.

  • Please contact support@wisencn.com for further information.

  • Common Software

    WiSen@ Programmer.zip: Firmware upgrade via WiSen Program Lead;
    WiSen@ SD Reader.zip: Data download or rescue from in a unit with SD card storage;
    WiSen@ Utility Software Centre.zip: including Serial Por Software: Data communication between a gateway and a Windows PC via a cable;
    TCP/IP Software: Data communication between a gateway and 3rd Party Server of a fixed public IP.     Note: Please refer to "Technical Document" for further instructions, at WiSen® Visualisation Platform.

    Leica GeoMos Specific

    Leica - WiSen Downloader: Software to integrate Wisen data into Leica GeoMos. Note: Downloadable from WiSen® Visualisation Platform, under /Download & Upload/Calibration & Document & Software/Software.

6B10 / 6B18 Type - 1/4-Channel Wheatstone/Full Bridge Interface Node

WiSenMeshWAN® Product @ 915, 868, 433MHz Radio Frequency
